SY9602 is a current-limiting IC integrating multiple protocols, with adjustable output limited current, PMOS switch with maximum limited current of 3A, D+/D supporting BC1.2 protocol, which provides automatic identification of mobile phones such as iPhone and Samsung, and ensures maximum charging power. SY9602 is available in a ESOP8 or DFN10 package.
Integrated PMOS switch with ultra-low impedance and 30mΩ conductor resistance, reverse output protection
Linearly adjustable maximum output current via external resistor
Ultra-low standby current: 80uA
Automatic switching between multiple USB charging protocols
Supports BC1.2 DCP and YD/T 1591-2009
Supports Divider 3 charging protocol, supports Apple devices
Applications for Samsung devices
Wall charger adapters
Car charger adapters
Power bank
USB charge/discharge ports
Other USB chargers
